• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	5.38 in
Bolt Size (in)	9/16 in
Overall Height (in)	2.167 in
Overall Length (in)	5.38 in
Bore Diameter (in)	1.5 in
Foot Height (in)	0.56 in
Length Through Bore (in)	2.06 in
Bolt Spacing (in)	4.1250 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	2.88 in
Inner Race Heat Treat Method	Zone-Hardened
Bearing Insert Material	52100 Bearing Steel
Max Operating Temperature (F)	220 °F
End Cap Available	No
Cage Type	Land Riding Retainer
Shaft Locking Type	Concentric
Grease Fitting Thread Size	1/4-28
Misalignment Capability	±2.0° Misalignment - Static Only
Static Load Rating (lb)	5,139 lb
Housing Coating	Powder Coated
Fixed vs. Expansion	Fixed
Radial Clearance	Standard
Dynamic Load Rating (lb)	7,901 lb
Housing Backside Inner Diameter	3.88
Bearing Type	Medium Duty
Size Code	2-111
Housing Material	Cast Iron
Insert	3-18T
Maximum Speed (RPM)	5300 rpm
Inner Ring Outside Diameter (in)	2.307 in
Bearing Insert Finish	Black Oxide
Lubricant	Lithium Complex NLGI 2 Grease

General Specifications

UPC	662461032152
Weight	6.36 LB
Packaged Length	6.06 IN
Packaged Width	5.94 IN
Packaged Height	2.19 IN
HTC	8483.20.4040
Country of Origin	Mexico
