• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	3.25 in
Overall Height (in)	7 in
Overall Length (in)	7 in
Bore Diameter (in)	3 in
Length Through Bore (in)	3.25 in
Centerline to Outermost Bearing Face (in)	1.94 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Construction	One Piece
Bore Shape	Straight
Housing Color	Gray
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Series	MSC
Cage Material	Brass
Seal Type	Felt Labyrinth Seal
Housing Type	Cartridge, Cylindrical
Housing Style	Cartridge Block
Outside Diameter (in)	7
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Max Operating Temperature (F)	220 °F
Shaft Locking Type	Set Screw
Bearing Insert Material	52100 Bearing Steel
Maximum Speed (RPM)	2250 rpm
End Cap Available	No
Dynamic Load Rating (lb)	17,412 lb
Static Load Rating (lb)	13,174 lb
Lubricant	Lithium Complex NLGI 2 Grease
Fixed vs. Expansion	Fixed
Size Code	2-33
Radial Clearance	Standard
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Material	Cast Iron
Cage Type	Land Riding Retainer
Bearing Type	Medium Duty
Inner Ring Outside Diameter (in)	3.922 in
Insert	3-3
Grease Fitting Thread Size	1/8 NPT
Bearing Insert Finish	Black Oxide
Housing Width (in)	2.19 in

General Specifications

UPC	662461014431
Weight	16.60 LB
Packaged Length	7.19 IN
Packaged Width	7.00 IN
Packaged Height	3.31 IN
HTC	8482.10.5056
Country of Origin	United States of America
