• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Length (in)	6.25 in
Overall Height (in)	6.25 in
Overall Width (in)	2.75 in
Bore Diameter (in)	2.4375 in
Length Through Bore (in)	2.75 in
Centerline to Outermost Bearing Face (in)	1.69 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Gray
Series	MSC
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Cartridge, Cylindrical
Seal Type	Felt Labyrinth Seal
Outside Diameter (in)	6.25
Housing Style	Cartridge Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Size Code	2-211
End Cap Available	No
Bearing Insert Material	52100 Bearing Steel
Bearing Type	Medium Duty
Bearing Insert Finish	Black Oxide
Insert	3-27
Static Load Rating (lb)	10,063 lb
Inner Ring Outside Diameter (in)	3.438 in
Shaft Locking Type	Set Screw
Fixed vs. Expansion	Fixed
Dynamic Load Rating (lb)	13,971 lb
Cage Type	Land Riding Retainer
Grease Fitting Thread Size	1/8 NPT
Radial Clearance	Standard
Max Operating Temperature (F)	220 °F
Lubricant	Lithium Complex NLGI 2 Grease
Maximum Speed (RPM)	2500 rpm
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Material	Cast Iron
Housing Width (in)	2 in

General Specifications

UPC	662461014394
Weight	12.60 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	3.06 IN
HTC	8482.10.5056
Country of Origin	United States of America
