• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal with black oxide bearing races
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Height (in)	4.94 in
Overall Width (in)	2.19 in
Overall Length (in)	4.94 in
Bore Diameter (in)	2 in
Length Through Bore (in)	2.188 in
Centerline to Outermost Bearing Face (in)	1.31 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Gray
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Series	MSC
Seal Type	Single Lip Contact Seal
Housing Type	Cartridge, Cylindrical
Housing Style	Cartridge Block
Outside Diameter (in)	4.938
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Cage Type	Land Riding Retainer
Grease Fitting Thread Size	1/8 NPT
Static Load Rating (lb)	6,601 lb
Maximum Speed (RPM)	2550 rpm
Lubricant	Lithium Complex NLGI 2 Grease
End Cap Available	No
Size Code	2-23
Max Operating Temperature (F)	220 °F
Dynamic Load Rating (lb)	9,752 lb
Fixed vs. Expansion	Fixed
Housing Material	Cast Iron
Misalignment Capability	±2.0° Misalignment - Static Only
Shaft Locking Type	Set Screw
Bearing Type	Medium Duty
Inner Ring Outside Diameter (in)	2.719 in
Insert	2-2C
Bearing Insert Material	52100 Bearing Steel
Bearing Insert Finish	Black Oxide
Radial Clearance	Standard
Housing Width (in)	1.59 in

General Specifications

UPC	662461027127
Weight	5.80 LB
Packaged Length	5.50 IN
Packaged Width	5.38 IN
Packaged Height	3.50 IN
HTC	8482.10.5052
Country of Origin	Mexico
