• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	2.25 in
Overall Height (in)	4.94 in
Overall Length (in)	4.94 in
Bore Diameter (in)	1.9375 in
Length Through Bore (in)	2.25 in
Centerline to Outermost Bearing Face (in)	1.45 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Construction	One Piece
Bore Shape	Straight
Misalignment Type	Static Only
Housing Color	Gray
Outer Ring Land Profile	Standard
Series	MSC-T
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Cartridge, Cylindrical
Seal Type	Felt Labyrinth Seal
Housing Style	Cartridge Block
Outside Diameter (in)	4.938
Locking Collar Outside Diameter (in)	3.6 in
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Radial Clearance	Standard
Maximum Speed (RPM)	4500 rpm
Max Operating Temperature (F)	220 °F
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Material	52100 Bearing Steel
Bearing Type	Medium Duty
Insert	3-115T
Cage Type	Land Riding Retainer
End Cap Available	No
Shaft Locking Type	Concentric
Bearing Insert Finish	Black Oxide
Dynamic Load Rating (lb)	9,752 lb
Size Code	2-23
Housing Material	Cast Iron
Misalignment Capability	±2.0° Misalignment - Static Only
Static Load Rating (lb)	6,601 lb
Inner Ring Outside Diameter (in)	2.719 in
Fixed vs. Expansion	Fixed
Grease Fitting Thread Size	1/4-28
Housing Width (in)	1.59 in

General Specifications

UPC	662461032077
Weight	6.72 LB
Packaged Length	5.50 IN
Packaged Width	5.38 IN
Packaged Height	3.50 IN
HTC	8482.10.5052
Country of Origin	Mexico
