• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	2.09 in
Overall Height (in)	4.56 in
Overall Length (in)	4.56 in
Bore Diameter (in)	1.75 in
Length Through Bore (in)	2.094 in
Centerline to Outermost Bearing Face (in)	1.42 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Gray
Series	MSC-T
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Cartridge, Cylindrical
Outside Diameter (in)	4.563
Housing Style	Cartridge Block
Locking Collar Outside Diameter (in)	3.35 in
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Insert	3-112T
Dynamic Load Rating (lb)	7,889 lb
Grease Fitting Thread Size	1/4-28
Inner Ring Outside Diameter (in)	2.469 in
Radial Clearance	Standard
Max Operating Temperature (F)	220 °F
Bearing Insert Material	52100 Bearing Steel
Cage Type	Land Riding Retainer
Bearing Type	Medium Duty
Bearing Insert Finish	Black Oxide
Maximum Speed (RPM)	5000 rpm
Shaft Locking Type	Concentric
Size Code	2-115
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Static Load Rating (lb)	5,216 lb
Lubricant	Lithium Complex NLGI 2 Grease
Housing Material	Cast Iron
End Cap Available	No
Housing Width (in)	1.47 in

General Specifications

UPC	662461032060
Weight	5.50 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8482.10.5052
Country of Origin	Mexico
