• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Air Handling noise check for quiet operation
• Looser than standard housing fit for ease of alignment on lightweight frames
• Felt labyrinth seal and flinger for dusty and dirty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Length (in)	13 in
Base Width (in)	3.50 in
Overall Width (in)	3.50 in
Overall Height (in)	7.00 in
Bolt Size (in)	7/8 in
Bore Diameter (in)	2.6875 in
Base to Center Height (in)	3.5000 in
Foot Height (in)	1.13 in
Length Through Bore (in)	3.063 in
Bolt Spacing Min (in)	7.88 in
Bolt Spacing Max (in)	10.13 in
Centerline to Outermost Bearing Face (in)	1.750 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Options	Air Handling Housing Fit, Noise Tested
Outer Ring Land Profile	Standard
Cage Material	Brass
Seal Type	Felt Labyrinth Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Setscrew Torque (in-lbs)	350-450 in/lbs
Housing Material	Cast Iron
Bearing Type	Medium Duty
Vibration Frequency Roller Spin	0.0476 cps
Grease Fitting Thread Size	1/8 NPT
Static Load Rating (lb)	11,224 lb
Vibration Frequency Fundamental Train	0.0069 cps
Housing Coating	Powder Coated
Dynamic Load Rating (lb)	14,839 lb
Insert	3-211
Size Code	2-215
Vibration Frequency Outer Ring Defect	0.0761 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Inner Ring Outside Diameter (in)	3.641 in
Vibration Frequency Inner Ring Defect	0.1072 cps
Fixed vs. Expansion	Fixed
Radial Clearance	Standard
Bearing Insert Finish	Black Oxide
Base Length (in)	13.00 in
Bearing Insert Material	52100 Bearing Steel
Shaft Locking Type	Set Screw
Lubricant	Lithium Complex NLGI 2 Grease
Max Operating Temperature (F)	220 °F
Cage Type	Land Riding Retainer
Maximum Speed (RPM)	2450 rpm
End Cap Available	No

General Specifications

UPC	662461078617
Weight	28.45 LB
Packaged Length	14.25 IN
Packaged Width	8.06 IN
Packaged Height	4.00 IN
HTC	8483.20.8040
Country of Origin	United States of America
