• Single lip contact seal with black oxide bearing races
• Fluoropolymer coated cast iron housing for corrosion resistance.
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.

Dimensions

Overall Length (in)	11.25 in
Base Width (in)	3.25 in
Overall Height (in)	6.25 in
Overall Width (in)	3.25 in
Bolt Size (in)	3/4 in
Bore Diameter (in)	2.4375 in
Foot Height (in)	1.06 in
Base to Center Height (in)	3.0000 in
Length Through Bore (in)	2.748 in
Bolt Spacing Max (in)	8.88 in
Centerline to Outermost Bearing Face (in)	1.688 in
Bolt Spacing Min (in)	7.13 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Gray
Options	Corrosion Resistant
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	Brass
Seal Type	Single Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Setscrew Torque (in-lbs)	350-450 in/lbs
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Base Length (in)	11.25 in
Housing Material	Cast Iron
Bearing Insert Material	52100 Bearing Steel
Radial Clearance	Standard
Cage Type	Land Riding Retainer
Insert	3-27C FG2
Vibration Frequency Roller Spin	0.0451 cps
Static Load Rating (lb)	10,063 lb
Bearing Insert Finish	Black Oxide
Dynamic Load Rating (lb)	13,971 lb
Vibration Frequency Fundamental Train	0.0068 cps
Grease Fitting Thread Size	1/8 NPT
Fixed vs. Expansion	Fixed
Maximum Speed (RPM)	2225 rpm
End Cap Available	No
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Outer Ring Defect	0.0684 cps
Shaft Locking Type	Set Screw
Inner Ring Outside Diameter (in)	3.438 in
Vibration Frequency Inner Ring Defect	0.0982 cps
Bearing Type	Medium Duty
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Size Code	2-211
Max Operating Temperature (F)	220 °F
Housing Coating	Flouropolymer Coated

General Specifications

UPC	662461240175
Weight	20.56 LB
Packaged Length	12.38 IN
Packaged Width	7.13 IN
Packaged Height	3.56 IN
HTC	8483.20.8040
Country of Origin	United States of America
