• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Base Width (in)	3.13 in
Overall Length (in)	10.25 in
Overall Height (in)	5.63 in
Overall Width (in)	3.13 in
Bolt Size (in)	3/4 in
Bore Diameter (in)	2.1875 in
Base to Center Height (in)	2.7500 in
Foot Height (in)	1.06 in
Length Through Bore (in)	2.625 in
Centerline to Outermost Bearing Face (in)	1.63 in
Bolt Spacing Max (in)	7.94 in
Bolt Spacing Min (in)	6.56 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	4.16 in
Setscrew Torque (in-lbs)	495 in/lbs
Vibration Frequency Outer Ring Defect	0.0678 cps
Size Code	2-27
Base Length (in)	10.25 in
Bearing Insert Finish	Black Oxide
Inner Ring Outside Diameter (in)	2.984 in
Dynamic Load Rating (lb)	11,789 lb
Vibration Frequency Roller Spin	0.0432 cps
Bearing Insert Material	52100 Bearing Steel
Fixed vs. Expansion	Fixed
Static Load Rating (lb)	8,150 lb
Cage Type	Land Riding Retainer
Housing Coating	Powder Coated
Vibration Frequency Inner Ring Defect	0.0989 cps
Radial Clearance	Standard
Shaft Locking Type	Concentric
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Material	Cast Iron
Vibration Frequency Fundamental Train	0.0068 cps
Grease Fitting Thread Size	1/8 NPT
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Type	Medium Duty
Max Operating Temperature (F)	220 °F
End Cap Available	No
Maximum Speed (RPM)	4100 rpm
Insert	3-23T

General Specifications

UPC	662461031902
Weight	17.45 LB
Packaged Length	6.50 IN
Packaged Width	10.38 IN
Packaged Height	3.00 IN
HTC	8483.20.8040
Country of Origin	United States of America
