• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal with black oxide bearing races
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Height (in)	5.09 in
Base Width (in)	2.88 in
Overall Length (in)	9.5 in
Overall Width (in)	2.88 in
Bolt Size (in)	5/8 in
Bore Diameter (in)	2 in
Foot Height (in)	0.88 in
Base to Center Height (in)	2.5000 in
Length Through Bore (in)	2.188 in
Centerline to Outermost Bearing Face (in)	1.313 in
Bolt Spacing Min (in)	5.94 in
Bolt Spacing Max (in)	7.56 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Radial Clearance	Standard
Bearing Insert Material	52100 Bearing Steel
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Inner Ring Defect	0.0987 cps
Dynamic Load Rating (lb)	9,752 lb
Vibration Frequency Outer Ring Defect	0.068 cps
Bearing Insert Finish	Black Oxide
Maximum Speed (RPM)	3250 rpm
Shaft Locking Type	Set Screw
Cage Type	Land Riding Retainer
Housing Coating	Powder Coated
Static Load Rating (lb)	6,601 lb
Housing Material	Cast Iron
Bearing Type	Medium Duty
Grease Fitting Thread Size	1/8 NPT
Insert	2-2C
Max Operating Temperature (F)	220 °F
Lubricant	Lithium Complex NLGI 2 Grease
Inner Ring Outside Diameter (in)	2.719 in
End Cap Available	No
Vibration Frequency Roller Spin	0.0437 cps
Size Code	2-23
Vibration Frequency Fundamental Train	0.0068 cps
Fixed vs. Expansion	Fixed
Base Length (in)	9.50 in

General Specifications

UPC	662461026700
Weight	11.74 LB
Packaged Length	9.68 IN
Packaged Width	5.69 IN
Packaged Height	3.19 IN
HTC	8483.20.8040
Country of Origin	United States of America
