• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Height (in)	4.56 in
Overall Width (in)	2.63 in
Base Width (in)	2.63 in
Overall Length (in)	8.75 in
Bolt Size (in)	5/8 in
Bore Diameter (in)	1.5 in
Foot Height (in)	0.81 in
Base to Center Height (in)	2.31 in
Length Through Bore (in)	1.938 in
Bolt Spacing Min (in)	5.5 in
Centerline to Outermost Bearing Face (in)	1.188 in
Bolt Spacing Max (in)	6.75 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Two Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Setscrew Torque (in-lbs)	125-165 in/lbs
Housing Coating	Powder Coated
Dynamic Load Rating (lb)	7,901 lb
Vibration Frequency Outer Ring Defect	0.0673 cps
Insert	3-18C
Grease Fitting Thread Size	1/4-28
Bearing Type	Medium Duty
End Cap Available	No
Housing Material	Cast Iron
Maximum Speed (RPM)	3800 rpm
Radial Clearance	Standard
Base Length (in)	8.75 in
Vibration Frequency Inner Ring Defect	0.0994 cps
Max Operating Temperature (F)	220 °F
Vibration Frequency Roller Spin	0.0417 cps
Size Code	2-111
Static Load Rating (lb)	5,139 lb
Shaft Locking Type	Set Screw
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Fundamental Train	0.0067 cps
Bearing Insert Finish	Black Oxide
Bearing Insert Material	52100 Bearing Steel
Cage Type	Land Riding Retainer
Lubricant	Lithium Complex NLGI 2 Grease
Fixed vs. Expansion	Fixed
Inner Ring Outside Diameter (in)	2.297 in

General Specifications

UPC	662461026663
Weight	8.90 LB
Packaged Length	9.25 IN
Packaged Width	5.12 IN
Packaged Height	3.00 IN
HTC	8483.20.8040
Country of Origin	United States of America
