• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking on both sides of ball path with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	5/8 in
Overall Width (in)	8.75 in
Overall Length (in)	8.75 in
Overall Height (in)	3.5 in
Bore Diameter (in)	2.6875 in
Pilot Diameter (in)	6.375 in
Foot Height (in)	0.56 in
Length Through Bore (in)	3.498 in
Housing Outside Diameter (in)	8.75 in
Bolt Circle (in)	7.5 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	Brass
Seal Type	Felt Labyrinth Seal
Housing Type	Flange, Piloted
Housing Style	Flange Block
Ability to Relubricate	Yes
Pilot Depth (in)	1.03 in
Inner Race Heat Treat Method	Zone-Hardened
Size Code	2-215
Housing Coating	Powder Coated
Max Operating Temperature (F)	220 °F
Housing Material	Cast Iron
Cage Type	Land Riding Retainer
Misalignment Capability	±2.0° Misalignment - Static Only
Shaft Locking Type	Double Set Screw
Dynamic Load Rating (lb)	14,839 lb
End Cap Available	No
Insert	3-211
Fixed vs. Expansion	Fixed
Grease Fitting Thread Size	1/8 NPT
Bearing Insert Finish	Black Oxide
Maximum Speed (RPM)	3600 rpm
Bearing Type	Medium Duty
Static Load Rating (lb)	11,224 lb
Radial Clearance	Standard
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Material	52100 Bearing Steel
Inner Ring Outside Diameter (in)	3.641 in

General Specifications

UPC	662461017067
Weight	18.95 LB
Packaged Length	8.88 IN
Packaged Width	8.88 IN
Packaged Height	3.88 IN
HTC	8483.20.4040
Country of Origin	United States of America
