• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	10.25 in
Bolt Size (in)	3/4 in
Overall Height (in)	3.78 in
Overall Length (in)	10.25 in
Bore Diameter (in)	3.4375 in
Foot Height (in)	0.75 in
Pilot Diameter (in)	7.375 in
Length Through Bore (in)	3.781 in
Housing Outside Diameter (in)	10.25 in
Bolt Circle (in)	8.625 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	Piloted
Housing Construction	One Piece
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	Brass
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Piloted
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Pilot Depth (in)	1.09 in
Ability to Relubricate	Yes
Bearing Insert Finish	Black Oxide
Static Load Rating (lb)	16,301 lb
Bearing Type	Medium Duty
Size Code	2-38
Maximum Speed (RPM)	1725 rpm
Shaft Locking Type	Set Screw
Fixed vs. Expansion	Fixed
Dynamic Load Rating (lb)	21,566 lb
End Cap Available	No
Radial Clearance	Standard
Housing Material	Cast Iron
Misalignment Capability	±2.0° Misalignment - Static Only
Max Operating Temperature (F)	220 °F
Cage Type	Land Riding Retainer
Insert	3-37C
Bearing Insert Material	52100 Bearing Steel
Grease Fitting Thread Size	1/4 NPT
Inner Ring Outside Diameter (in)	4.391 in
Lubricant	Lithium Complex NLGI 2 Grease
Housing Coating	Powder Coated

General Specifications

UPC	662461026410
Weight	30.49 LB
Packaged Length	10.63 IN
Packaged Width	10.44 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	United States of America
