• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	5/8 in
Overall Width (in)	8.75 in
Overall Length (in)	8.75 in
Overall Height (in)	3.25 in
Bore Diameter (in)	3 in
Pilot Diameter (in)	6.375 in
Foot Height (in)	0.63 in
Length Through Bore (in)	3.248 in
Housing Outside Diameter (in)	8.75 in
Bolt Circle (in)	7.5 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	Brass
Housing Type	Flange, Piloted
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Pilot Depth (in)	1.22 in
Cage Type	Land Riding Retainer
Bearing Insert Material	52100 Bearing Steel
Radial Clearance	Standard
Inner Ring Outside Diameter (in)	3.922 in
Lubricant	Lithium Complex NLGI 2 Grease
Housing Coating	Powder Coated
Grease Fitting Thread Size	1/4 NPT
Housing Material	Cast Iron
Fixed vs. Expansion	Fixed
Static Load Rating (lb)	13,174 lb
Insert	3-3C
End Cap Available	No
Bearing Type	Medium Duty
Bearing Insert Finish	Black Oxide
Maximum Speed (RPM)	1950 rpm
Size Code	2-33
Shaft Locking Type	Set Screw
Max Operating Temperature (F)	220 °F
Misalignment Capability	±2.0° Misalignment - Static Only
Dynamic Load Rating (lb)	17,412 lb

General Specifications

UPC	662461026397
Weight	19.10 LB
Packaged Length	9.06 IN
Packaged Width	8.88 IN
Packaged Height	3.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
