• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	8.75 in
Bolt Size (in)	5/8 in
Overall Length (in)	8.75 in
Overall Height (in)	3.06 in
Bore Diameter (in)	2.6875 in
Pilot Diameter (in)	6.375 in
Foot Height (in)	0.56 in
Length Through Bore (in)	3.06 in
Housing Outside Diameter (in)	8.75 in
Bolt Circle (in)	7.5 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	Brass
Housing Type	Flange, Piloted
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Pilot Depth (in)	1.03 in
Inner Race Heat Treat Method	Zone-Hardened
Cage Type	Land Riding Retainer
Radial Clearance	Standard
End Cap Available	No
Housing Coating	Powder Coated
Max Operating Temperature (F)	220 °F
Shaft Locking Type	Set Screw
Static Load Rating (lb)	11,224 lb
Insert	3-211C
Bearing Insert Finish	Black Oxide
Dynamic Load Rating (lb)	14,839 lb
Size Code	2-215
Grease Fitting Thread Size	1/8 NPT
Bearing Insert Material	52100 Bearing Steel
Lubricant	Lithium Complex NLGI 2 Grease
Maximum Speed (RPM)	2100 rpm
Bearing Type	Medium Duty
Misalignment Capability	±2.0° Misalignment - Static Only
Inner Ring Outside Diameter (in)	3.641 in
Housing Material	Cast Iron
Fixed vs. Expansion	Fixed

General Specifications

UPC	662461026373
Weight	18.35 LB
Packaged Length	9.06 IN
Packaged Width	8.88 IN
Packaged Height	3.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
