• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	7.63 in
Bolt Size (in)	1/2 in
Overall Height (in)	2.84 in
Overall Length (in)	7.63 in
Bore Diameter (in)	2.4375 in
Pilot Diameter (in)	5.500 in
Foot Height (in)	0.56 in
Length Through Bore (in)	2.748 in
Housing Outside Diameter (in)	7.63 in
Bolt Circle (in)	6.5 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	Piloted
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	Brass
Housing Type	Flange, Piloted
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Pilot Depth (in)	1.094 in
Cage Type	Land Riding Retainer
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Finish	Black Oxide
Max Operating Temperature (F)	220 °F
Bearing Type	Medium Duty
Inner Ring Outside Diameter (in)	3.438 in
Insert	3-27C
Grease Fitting Thread Size	1/8 NPT
Bearing Insert Material	52100 Bearing Steel
Maximum Speed (RPM)	2225 rpm
Fixed vs. Expansion	Fixed
Radial Clearance	Standard
Shaft Locking Type	Set Screw
Size Code	2-211
Housing Coating	Powder Coated
End Cap Available	No
Dynamic Load Rating (lb)	13,971 lb
Housing Material	Cast Iron
Misalignment Capability	±2.0° Misalignment - Static Only
Static Load Rating (lb)	10,063 lb

General Specifications

UPC	662461026359
Weight	12.90 LB
Packaged Length	8.13 IN
Packaged Width	7.94 IN
Packaged Height	3.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
