• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	6.38 in
Bolt Size (in)	7/16 in
Overall Length (in)	6.38 in
Overall Height (in)	2.33 in
Bore Diameter (in)	1.9375 in
Pilot Diameter (in)	4.500 in
Foot Height (in)	0.44 in
Length Through Bore (in)	2.33 in
Housing Outside Diameter (in)	6.38 in
Bolt Circle (in)	5.375 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Piloted
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Pilot Depth (in)	.625 in
Locking Collar Outside Diameter (in)	3.5 in
Inner Ring Outside Diameter (in)	2.719 in
Housing Coating	Powder Coated
Fixed vs. Expansion	Fixed
Static Load Rating (lb)	6,601 lb
Housing Material	Cast Iron
Bearing Insert Finish	Black Oxide
Insert	3-115TC
Dynamic Load Rating (lb)	9,752 lb
End Cap Available	No
Grease Fitting Thread Size	1/8 NPT
Maximum Speed (RPM)	3250 rpm
Misalignment Capability	±2.0° Misalignment - Static Only
Cage Type	Land Riding Retainer
Max Operating Temperature (F)	220 °F
Bearing Insert Material	52100 Bearing Steel
Bearing Type	Medium Duty
Size Code	2-23
Radial Clearance	Standard
Shaft Locking Type	Concentric
Lubricant	Lithium Complex NLGI 2 Grease

General Specifications

UPC	662461034743
Weight	7.80 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
