• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	6.38 in
Bolt Size (in)	7/16 in
Overall Height (in)	2.19 in
Overall Length (in)	6.38 in
Bore Diameter (in)	1.9375 in
Pilot Diameter (in)	4.500 in
Foot Height (in)	0.44 in
Length Through Bore (in)	2.188 in
Housing Outside Diameter (in)	6.38 in
Bolt Circle (in)	5.375 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Piloted
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Pilot Depth (in)	.625 in
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Shaft Locking Type	Set Screw
Radial Clearance	Standard
Max Operating Temperature (F)	220 °F
Housing Material	Cast Iron
End Cap Available	No
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	9,752 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Size Code	2-23
Insert	3-115
Static Load Rating (lb)	6,601 lb
Grease Fitting Thread Size	1/8 NPT
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Finish	Black Oxide
Fixed vs. Expansion	Fixed
Inner Ring Outside Diameter (in)	2.719 in
Bearing Insert Material	52100 Bearing Steel
Maximum Speed (RPM)	3250 rpm
Housing Coating	Powder Coated
Bearing Type	Medium Duty

General Specifications

UPC	662461013403
Weight	7.25 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
