• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	7/16 in
Overall Width (in)	6.13 in
Overall Height (in)	2.03 in
Bolt Size (mm)	M12 mm
Overall Length (in)	6.13 in
Bore Diameter (mm)	45 mm
Foot Height (in)	0.44 in
Pilot Diameter (in)	4.25 in
Length Through Bore (in)	2.029 in
Bolt Circle (in)	5.125 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Flange, Piloted
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Pilot Depth (in)	0.44 in
Housing Material	Cast Iron
Fixed vs. Expansion	Fixed
Bearing Insert Finish	Black Oxide
Insert	5309
Static Load Rating (lb)	5,216 lb
End Cap Available	No
Vibration Frequency Fundamental Train	0.0068 cps
Grease Fitting Thread Size	1/8 NPT
Inner Ring Outside Diameter (in)	2.469 in
Max Operating Temperature (F)	220 °F
Vibration Frequency Outer Ring Defect	0.0683 cps
Housing Coating	Powder Coated
Vibration Frequency Roller Spin	0.0445 cps
Lubricant	Lithium Complex NLGI 2 Grease
Radial Clearance	Standard
Misalignment Capability	±2.0° Misalignment - Static Only
Size Code	2-115
Vibration Frequency Inner Ring Defect	0.0984 cps
Bearing Insert Material	52100 Bearing Steel
Bearing Type	Medium Duty
Shaft Locking Type	Set Screw
Dynamic Load Rating (lb)	7,889 lb
Maximum Speed (RPM)	3550 rpm
Cage Type	Land Riding Retainer

General Specifications

UPC	662461053799
Weight	6.50 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
