• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	5.25 in
Bolt Size (in)	3/8 in
Overall Length (in)	5.25 in
Bolt Size (mm)	M10 mm
Overall Height (in)	1.94 in
Bore Diameter (mm)	35 mm
Foot Height (in)	0.44 in
Pilot Diameter (in)	3.625 in
Length Through Bore (in)	1.935 in
Bolt Circle (in)	4.375 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Flange, Piloted
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Pilot Depth (in)	0.41 in
Ability to Relubricate	Yes
Inner Ring Outside Diameter (in)	2.063 in
Max Operating Temperature (F)	220 °F
Static Load Rating (lb)	4,467 lb
Housing Coating	Powder Coated
Dynamic Load Rating (lb)	7,340 lb
Vibration Frequency Inner Ring Defect	0.0909 cps
Cage Type	Land Riding Retainer
Misalignment Capability	±2.0° Misalignment - Static Only
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Material	52100 Bearing Steel
Radial Clearance	Standard
Vibration Frequency Fundamental Train	0.0066 cps
Housing Material	Cast Iron
Maximum Speed (RPM)	4150 rpm
Grease Fitting Thread Size	1/4-28
Bearing Type	Medium Duty
End Cap Available	No
Vibration Frequency Outer Ring Defect	0.0591 cps
Vibration Frequency Roller Spin	0.0376 cps
Insert	5307
Shaft Locking Type	Set Screw
Bearing Insert Finish	Black Oxide
Size Code	2-19
Fixed vs. Expansion	Fixed

General Specifications

UPC	662461053775
Weight	4.90 LB
Packaged Length	2.13 IN
Packaged Width	5.50 IN
Packaged Height	5.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
