• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	6.13 in
Bolt Size (in)	7/16 in
Overall Height (in)	2.03 in
Overall Length (in)	6.13 in
Bore Diameter (in)	1.6875 in
Pilot Diameter (in)	4.25 in
Foot Height (in)	0.44 in
Length Through Bore (in)	2.029 in
Housing Outside Diameter (in)	6.13 in
Bolt Circle (in)	5.125 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Piloted
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Pilot Depth (in)	0.44 in
Cage Type	Land Riding Retainer
Static Load Rating (lb)	5,216 lb
Vibration Frequency Fundamental Train	0.0068 cps
Bearing Type	Medium Duty
Bearing Insert Material	52100 Bearing Steel
Housing Material	Cast Iron
Housing Coating	Powder Coated
Max Operating Temperature (F)	220 °F
Inner Ring Outside Diameter (in)	2.469 in
Bearing Insert Finish	Black Oxide
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Outer Ring Defect	0.0683 cps
Dynamic Load Rating (lb)	7,889 lb
Vibration Frequency Roller Spin	0.0445 cps
Maximum Speed (RPM)	3550 rpm
Grease Fitting Thread Size	1/8 NPT
Shaft Locking Type	Set Screw
Size Code	2-115
Vibration Frequency Inner Ring Defect	0.0984 cps
End Cap Available	No
Insert	3-111C
Fixed vs. Expansion	Fixed
Radial Clearance	Standard
Lubricant	Lithium Complex NLGI 2 Grease

General Specifications

UPC	662461026298
Weight	6.60 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
