• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	5.25 in
Bolt Size (in)	3/8 in
Overall Height (in)	1.94 in
Overall Length (in)	5.25 in
Bore Diameter (in)	1.4375 in
Pilot Diameter (in)	3.625 in
Foot Height (in)	0.44 in
Length Through Bore (in)	1.935 in
Housing Outside Diameter (in)	5.25 in
Bolt Circle (in)	4.375 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	Piloted
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Piloted
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Pilot Depth (in)	0.41 in
Inner Race Heat Treat Method	Zone-Hardened
Shaft Locking Type	Set Screw
Grease Fitting Thread Size	1/4-28
Vibration Frequency Outer Ring Defect	0.0591 cps
Housing Coating	Powder Coated
Bearing Insert Finish	Black Oxide
Vibration Frequency Inner Ring Defect	0.0909 cps
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Roller Spin	0.0376 cps
Dynamic Load Rating (lb)	7,340 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Fixed vs. Expansion	Fixed
Insert	3-17C
Radial Clearance	Standard
Vibration Frequency Fundamental Train	0.0066 cps
Cage Type	Land Riding Retainer
End Cap Available	No
Bearing Insert Material	52100 Bearing Steel
Housing Material	Cast Iron
Size Code	2-19
Maximum Speed (RPM)	4150 rpm
Static Load Rating (lb)	4,467 lb
Max Operating Temperature (F)	220 °F
Bearing Type	Medium Duty
Inner Ring Outside Diameter (in)	2.063 in

General Specifications

UPC	662461026267
Weight	4.70 LB
Packaged Length	5.50 IN
Packaged Width	2.13 IN
Packaged Height	5.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
