• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	3/8 in
Overall Width (in)	5 in
Overall Height (in)	1.69 in
Overall Length (in)	5 in
Bore Diameter (in)	1.25 in
Pilot Diameter (in)	3.375 in
Foot Height (in)	0.38 in
Length Through Bore (in)	1.688 in
Housing Outside Diameter (in)	5 in
Bolt Circle (in)	4.125 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Piloted
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Pilot Depth (in)	0.38 in
Maximum Speed (RPM)	4650 rpm
Bearing Type	Medium Duty
Inner Ring Outside Diameter (in)	1.859 in
Lubricant	Lithium Complex NLGI 2 Grease
Fixed vs. Expansion	Fixed
Bearing Insert Finish	Black Oxide
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Inner Ring Defect	0.0905 cps
Vibration Frequency Fundamental Train	0.0066 cps
Housing Material	Cast Iron
Grease Fitting Thread Size	1/4-28
Radial Clearance	Standard
Insert	2-14C
Max Operating Temperature (F)	220 °F
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	5,782 lb
End Cap Available	No
Housing Coating	Powder Coated
Vibration Frequency Roller Spin	0.0386 cps
Size Code	2-17
Vibration Frequency Outer Ring Defect	0.0595 cps
Static Load Rating (lb)	3,493 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Shaft Locking Type	Set Screw

General Specifications

UPC	662461026250
Weight	3.66 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8483.20.4040
Country of Origin	United States of America
