• Powder coated epoxy cast iron housing machined housing for end cap
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• High Temperature seals
• High temperature grease with grease drain/purge port
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® customer lock pin for anti-rotation

Dimensions

Overall Width (in)	5.63 in
Bolt Size (in)	9/16 in
Overall Length (in)	5.63 in
Overall Height (in)	2.156 in
Bore Diameter (in)	1.9375 in
Foot Height (in)	0.56 in
Length Through Bore (in)	2.027 in
Bolt Spacing (in)	4.3750 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Options	Furnace Bearing
Misalignment Type	Static Only
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	V Spring Seal Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Insert	2-115
Misalignment Capability	±2.0° Misalignment - Static Only
Maximum Speed (RPM)	3550 rpm
Radial Clearance	Increased
Bearing Insert Finish	Black Oxide
Bearing Type	Standard Duty
Fixed vs. Expansion	Fixed
Cage Type	Land Riding Retainer
Lubricant	Lithium Complex Grease With Synthetic Oil
Dynamic Load Rating (lb)	7,889 lb
End Cap Available	No
Grease Fitting Thread Size	1/8 NPT
Shaft Locking Type	Set Screw
Housing Material	Cast Iron
Housing Coating	Powder Coated
Housing Backside Inner Diameter	4
Max Operating Temperature (F)	220 °F
Bearing Insert Material	52100 Bearing Steel
Static Load Rating (lb)	5,216 lb
Size Code	2-115
Inner Ring Outside Diameter (in)	2.469 in

General Specifications

UPC	662461276563
Weight	6.10 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
