• Powder coated epoxy cast iron housing machined housing for end cap
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• High Temperature seals
• High temperature grease with grease drain/purge port
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® customer lock pin for anti-rotation

Dimensions

Overall Width (in)	5.38 in
Bolt Size (in)	9/16 in
Overall Height (in)	2.047 in
Overall Length (in)	5.38 in
Bore Diameter (in)	1.75 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.934 in
Bolt Spacing (in)	4.125 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Options	Furnace Bearing
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	V Spring Seal Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Static Load Rating (lb)	5,139 lb
End Cap Available	No
Housing Material	Cast Iron
Maximum Speed (RPM)	1500 rpm
Housing Backside Inner Diameter	3.88
Bearing Type	Standard Duty
Shaft Locking Type	Set Screw
Size Code	2-111
Fixed vs. Expansion	Fixed
Bearing Insert Finish	Black Oxide
Cage Type	Land Riding Retainer
Grease Fitting Thread Size	1/4-28
Insert	2-112
Lubricant	Lithium Complex Grease With Synthetic Oil
Dynamic Load Rating (lb)	7,901 lb
Bearing Insert Material	52100 Bearing Steel
Radial Clearance	Increased
Inner Ring Outside Diameter (in)	2.307 in
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Coating	Powder Coated
Max Operating Temperature (F)	400 °F

General Specifications

UPC	662461231180
Weight	5.72 LB
Packaged Length	6.06 IN
Packaged Width	5.94 IN
Packaged Height	2.19 IN
HTC	8483.20.4040
Country of Origin	United States of America
