• Cast iron housed, extended inner ring bearing with ball riding nylon retainer
• Designed to accommodate optional closed or open end to allow users to better conform OSHA requirements for personal protection
• Skwezloc® Concentric locking for near perfect concentricity
• Single lip contact seal and flinger
• Supplied sealed for life with optional lubrication fitting in the box

Dimensions

Overall Width (in)	3.75 in
Bolt Size (in)	1/2 in
Overall Height (in)	1.94 in
Overall Length (in)	6.13 in
Bore Diameter (in)	1.4375 in
Foot Height (in)	0.5 in
Base to Center Height (in)	4.25 in
Overall Height to End Cap (in)	2.78 in
Length Through Bore (in)	1.81 in
Bolt Spacing (in)	2.0000 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal with Flinger
Housing Type	Flange, Bracket, Three Bolt
Housing Style	Flange Block
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	2.50 in
Inner Race Heat Treat Method	Zone-Hardened
Radial Clearance	Standard
Vibration Frequency Roller Spin	0.0386 cps
Lubricant	Lithium Complex NLGI 2 Grease
Shaft Locking Type	Concentric
Vibration Frequency Inner Ring Defect	0.0905 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Size Code	2-17
Dynamic Load Rating (lb)	5,782 lb
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Fundamental Train	0.0066 cps
Bearing Insert Finish	Black Oxide
Inner Ring Outside Diameter (in)	1.862 in
Housing Coating	Powder Coated
Max Operating Temperature (F)	220 °F
Vibration Frequency Outer Ring Defect	0.0595 cps
Cage Type	Land Riding Retainer
Bolt Spacing Height Direction (in)	1.25 in
Housing Material	Cast Iron
Maximum Speed (RPM)	4000 rpm
Grease Fitting Thread Size	1/4-28
Bearing Centerline to Bolt Hole Center (in)	2.375 in
End Cap Available	No
Static Load Rating (lb)	3,493 lb
Fixed vs. Expansion	Fixed
Bearing Type	Standard Duty
Insert	MH-23T
Housing Width (in)	3.75 in

General Specifications

UPC	662461341032
Weight	3.66 LB
Packaged Length	7.20 IN
Packaged Width	4.50 IN
Packaged Height	2.10 IN
HTC	8483.20.4040
Country of Origin	Mexico
