• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	1/2 in
Overall Width (in)	4.56 in
Overall Length (in)	7.47 in
Overall Height (in)	2.31 in
Bore Diameter (in)	2 in
Base to Center Height (in)	5.19 in
Foot Height (in)	0.5 in
Length Through Bore (in)	2.17 in
Bolt Spacing (in)	2.7500 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Bracket, Three Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Locking Collar Outside Diameter (in)	3.47 in
Setscrew Torque (in-lbs)	240 in/lbs
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Insert	1-2TC
Bearing Insert Finish	Black Oxide
End Cap Available	No
Inner Ring Outside Diameter (in)	2.469 in
Housing Material	Cast Iron
Static Load Rating (lb)	5,216 lb
Housing Coating	Powder Coated
Max Operating Temperature (F)	220 °F
Radial Clearance	Standard
Bolt Spacing Height Direction (in)	1.625 in
Lubricant	Lithium Complex NLGI 2 Grease
Shaft Locking Type	Concentric
Vibration Frequency Fundamental Train	0.0068 cps
Fixed vs. Expansion	Fixed
Cage Type	Land Riding Retainer
Size Code	2-115
Bearing Centerline to Bolt Hole Center (in)	2.9375 in
Grease Fitting Thread Size	1/8 NPT
Vibration Frequency Inner Ring Defect	0.0984 cps
Maximum Speed (RPM)	3550 rpm
Dynamic Load Rating (lb)	7,889 lb
Bearing Insert Material	52100 Bearing Steel
Bearing Type	Standard Duty
Vibration Frequency Outer Ring Defect	0.0683 cps
Vibration Frequency Roller Spin	0.0445 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Width (in)	4.56 in

General Specifications

UPC	662461097755
Weight	5.70 LB
Packaged Length	5.19 IN
Packaged Width	2.13 IN
Packaged Height	7.81 IN
HTC	8483.20.4040
Country of Origin	United States of America
