• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	4.56 in
Bolt Size (in)	1/2 in
Overall Length (in)	7.47 in
Overall Height (in)	2.31 in
Bore Diameter (in)	1.9375 in
Foot Height (in)	0.5 in
Base to Center Height (in)	5.19 in
Length Through Bore (in)	2.17 in
Bolt Spacing (in)	2.7500 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Bracket, Three Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Setscrew Torque (in-lbs)	240 in/lbs
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	3.47 in
Vibration Frequency Inner Ring Defect	0.0984 cps
Insert	2-115T
Inner Ring Outside Diameter (in)	2.469 in
Vibration Frequency Roller Spin	0.0445 cps
Max Operating Temperature (F)	220 °F
Bearing Insert Finish	Black Oxide
Static Load Rating (lb)	5,216 lb
Maximum Speed (RPM)	5000 rpm
Grease Fitting Thread Size	1/8 NPT
Housing Coating	Powder Coated
Size Code	2-115
Cage Type	Land Riding Retainer
Vibration Frequency Outer Ring Defect	0.0683 cps
Lubricant	Lithium Complex NLGI 2 Grease
Bolt Spacing Height Direction (in)	1.625 in
Bearing Insert Material	52100 Bearing Steel
Bearing Centerline to Bolt Hole Center (in)	2.9375 in
Radial Clearance	Standard
Shaft Locking Type	Concentric
Fixed vs. Expansion	Fixed
Housing Material	Cast Iron
Bearing Type	Standard Duty
Vibration Frequency Fundamental Train	0.0068 cps
End Cap Available	No
Dynamic Load Rating (lb)	7,889 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Width (in)	4.56 in

General Specifications

UPC	662461031681
Weight	6.60 LB
Packaged Length	5.19 IN
Packaged Width	2.13 IN
Packaged Height	7.81 IN
HTC	8483.20.4040
Country of Origin	United States of America
