• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.

Dimensions

Overall Width (in)	3.75 in
Bolt Size (in)	1/2 in
Overall Height (in)	1.94 in
Overall Length (in)	6.13 in
Bore Diameter (in)	1.4375 in
Base to Center Height (in)	4.25 in
Foot Height (in)	0.5 in
Length Through Bore (in)	1.81 in
Bolt Spacing (in)	2.0000 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Tapered Lands
Options	Reduced Maintenance - Lubed for Life
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Bracket, Three Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Ability to Relubricate	No
Locking Collar Outside Diameter (in)	2.50 in
Inner Race Heat Treat Method	Zone-Hardened
Cage Type	Land Riding Retainer
Vibration Frequency Inner Ring Defect	0.0905 cps
Dynamic Load Rating (lb)	5,782 lb
Size Code	2-17
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Centerline to Bolt Hole Center (in)	2.375 in
Fixed vs. Expansion	Fixed
Static Load Rating (lb)	3,493 lb
Inner Ring Outside Diameter (in)	1.862 in
Bolt Spacing Height Direction (in)	1.25 in
Vibration Frequency Fundamental Train	0.0066 cps
Insert	2-17T
Max Operating Temperature (F)	220 °F
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Finish	Black Oxide
Bearing Insert Material	52100 Bearing Steel
End Cap Available	No
Grease Fitting Thread Size	1/4-28
Vibration Frequency Outer Ring Defect	0.0595 cps
Housing Material	Cast Iron
Shaft Locking Type	Concentric
Maximum Speed (RPM)	6500 rpm
Bearing Type	Standard Duty
Radial Clearance	Standard
Vibration Frequency Roller Spin	0.0386 cps
Housing Coating	Powder Coated
Housing Width (in)	3.75 in

General Specifications

UPC	662461343555
Weight	3.40 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.4040
Country of Origin	United States of America
