• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal with black oxide bearing races
• Metric fitting and mounting bolts
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	2.75 in
Bolt Size (in)	3/8 in
Overall Height (in)	1.61 in
Overall Length (in)	4.75 in
Bolt Size (mm)	M10 mm
Bore Diameter (mm)	25 mm
Foot Height (in)	0.38 in
Base to Center Height (in)	3.38 in
Length Through Bore (in)	1.48 in
Bolt Spacing (in)	1.6250 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Bracket, Three Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Locking Collar Outside Diameter (in)	1.98 in
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Bearing Insert Finish	Black Oxide
Dynamic Load Rating (lb)	2,801 lb
Grease Fitting Thread Size	1/4-28
Bearing Type	Standard Duty
Static Load Rating (lb)	1,651 lb
Maximum Speed (RPM)	6350 rpm
Vibration Frequency Roller Spin	0.0442 cps
Size Code	2-015
Bolt Spacing Height Direction (in)	1.125 in
Inner Ring Outside Diameter (in)	1.375 in
Shaft Locking Type	Concentric
Max Operating Temperature (F)	220 °F
Housing Coating	Powder Coated
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Inner Ring Defect	0.0985 cps
Insert	5205TMC
Housing Material	Cast Iron
Fixed vs. Expansion	Fixed
Bearing Centerline to Bolt Hole Center (in)	1.8125 in
Cage Type	Land Riding Retainer
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Fundamental Train	0.0068 cps
Radial Clearance	Standard
Vibration Frequency Outer Ring Defect	0.0682 cps
End Cap Available	No
Housing Width (in)	2.75 in

General Specifications

UPC	662461235966
Weight	2.30 LB
Packaged Length	3.19 IN
Packaged Width	1.69 IN
Packaged Height	5.25 IN
HTC	8483.20.4040
Country of Origin	United States of America
