• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	2.38 in
Bolt Size (in)	3/8 in
Overall Length (in)	4.19 in
Overall Height (in)	1.34 in
Bore Diameter (mm)	20 mm
Foot Height (in)	0.31 in
Base to Center Height (in)	3 in
Length Through Bore (in)	1.219 in
Bolt Spacing (in)	1.5 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Bracket, Three Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Misalignment Capability	±2.0° Misalignment - Static Only
Insert	5204
Lubricant	Lithium Complex NLGI 2 Grease
Size Code	2-012
Bearing Centerline to Bolt Hole Center (in)	1.6875 in
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Outer Ring Defect	0.0593 cps
Vibration Frequency Fundamental Train	0.0066 cps
Radial Clearance	Standard
End Cap Available	No
Max Operating Temperature (F)	220 °F
Maximum Speed (RPM)	7300 rpm
Bearing Insert Finish	Black Oxide
Vibration Frequency Inner Ring Defect	0.0907 cps
Dynamic Load Rating (lb)	2,611 lb
Fixed vs. Expansion	Fixed
Bolt Spacing Height Direction (in)	0.875 in
Grease Fitting Thread Size	1/4-28
Housing Coating	Powder Coated
Bearing Type	Standard Duty
Vibration Frequency Roller Spin	0.0381 cps
Cage Type	Land Riding Retainer
Shaft Locking Type	Set Screw
Inner Ring Outside Diameter (in)	1.192 in
Static Load Rating (lb)	1,444 lb
Housing Material	Cast Iron
Housing Width (in)	2.38 in

General Specifications

UPC	662461053188
Weight	1.57 LB
Packaged Length	1.50 IN
Packaged Width	4.00 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	United States of America
