• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	1/2 in
Overall Width (in)	3.75 in
Overall Height (in)	1.88 in
Overall Length (in)	6.13 in
Bore Diameter (in)	1.25 in
Foot Height (in)	0.5 in
Base to Center Height (in)	4.25 in
Length Through Bore (in)	1.685 in
Bolt Spacing (in)	2.0000 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Bracket, Three Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Maximum Speed (RPM)	4650 rpm
Static Load Rating (lb)	3,493 lb
Fixed vs. Expansion	Fixed
Bearing Insert Material	52100 Bearing Steel
Shaft Locking Type	Set Screw
Bolt Spacing Height Direction (in)	1.25 in
Vibration Frequency Roller Spin	0.0386 cps
Max Operating Temperature (F)	220 °F
Vibration Frequency Outer Ring Defect	0.0595 cps
Radial Clearance	Standard
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Inner Ring Defect	0.0905 cps
Insert	2-14
Bearing Type	Standard Duty
End Cap Available	No
Grease Fitting Thread Size	1/4-28
Inner Ring Outside Diameter (in)	1.862 in
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Centerline to Bolt Hole Center (in)	2.375 in
Size Code	2-17
Dynamic Load Rating (lb)	5,782 lb
Housing Material	Cast Iron
Housing Coating	Powder Coated
Vibration Frequency Fundamental Train	0.0066 cps
Cage Type	Land Riding Retainer
Bearing Insert Finish	Black Oxide
Housing Width (in)	3.75 in

General Specifications

UPC	662461010211
Weight	3.78 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.4040
Country of Origin	United States of America
