• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	3.22 in
Bolt Size (in)	3/8 in
Overall Height (in)	1.63 in
Overall Length (in)	5.38 in
Bore Diameter (in)	1.1875 in
Foot Height (in)	0.38 in
Base to Center Height (in)	3.75 in
Length Through Bore (in)	1.5 in
Bolt Spacing (in)	1.8750 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Flange, Bracket, Three Bolt
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Type	Standard Duty
Dynamic Load Rating (lb)	4,381 lb
Bolt Spacing Height Direction (in)	1.25 in
Radial Clearance	Standard
Maximum Speed (RPM)	5450 rpm
Fixed vs. Expansion	Fixed
Inner Ring Outside Diameter (in)	1.594 in
Size Code	2-13
End Cap Available	No
Insert	2-13
Cage Type	Land Riding Retainer
Vibration Frequency Inner Ring Defect	0.0905 cps
Vibration Frequency Fundamental Train	0.0066 cps
Vibration Frequency Roller Spin	0.0385 cps
Lubricant	Lithium Complex NLGI 2 Grease
Max Operating Temperature (F)	220 °F
Housing Material	Cast Iron
Bearing Insert Material	52100 Bearing Steel
Housing Coating	Powder Coated
Bearing Insert Finish	Black Oxide
Shaft Locking Type	Set Screw
Bearing Centerline to Bolt Hole Center (in)	2.0625 in
Grease Fitting Thread Size	1/4-28
Static Load Rating (lb)	2,567 lb
Vibration Frequency Outer Ring Defect	0.0595 cps
Housing Width (in)	3.22 in

General Specifications

UPC	662461010198
Weight	2.25 LB
Packaged Length	1.69 IN
Packaged Width	3.50 IN
Packaged Height	5.75 IN
HTC	8483.20.4040
Country of Origin	United States of America
