• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	2.75 in
Bolt Size (in)	3/8 in
Overall Length (in)	4.75 in
Overall Height (in)	1.61 in
Bore Diameter (in)	1 in
Base to Center Height (in)	3.38 in
Foot Height (in)	0.38 in
Length Through Bore (in)	1.48 in
Bolt Spacing (in)	1.6250 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Bracket, Three Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Locking Collar Outside Diameter (in)	1.98 in
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Misalignment Capability	±2.0° Misalignment - Static Only
Insert	2-1T
Maximum Speed (RPM)	9000 rpm
Bearing Insert Material	52100 Bearing Steel
Grease Fitting Thread Size	1/4-28
Bearing Centerline to Bolt Hole Center (in)	1.8125 in
Static Load Rating (lb)	1,651 lb
Cage Type	Land Riding Retainer
Size Code	2-015
Inner Ring Outside Diameter (in)	1.375 in
Fixed vs. Expansion	Fixed
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Outer Ring Defect	0.0682 cps
Vibration Frequency Roller Spin	0.0442 cps
Vibration Frequency Fundamental Train	0.0068 cps
Bearing Type	Standard Duty
Dynamic Load Rating (lb)	2,801 lb
Max Operating Temperature (F)	220 °F
End Cap Available	No
Bolt Spacing Height Direction (in)	1.125 in
Bearing Insert Finish	Black Oxide
Shaft Locking Type	Concentric
Housing Material	Cast Iron
Housing Coating	Powder Coated
Vibration Frequency Inner Ring Defect	0.0985 cps
Radial Clearance	Standard
Housing Width (in)	2.75 in

General Specifications

UPC	662461031599
Weight	1.82 LB
Packaged Length	1.69 IN
Packaged Width	3.19 IN
Packaged Height	5.25 IN
HTC	8483.20.4040
Country of Origin	United States of America
