• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	3/8 in
Overall Width (in)	2.75 in
Overall Length (in)	4.75 in
Overall Height (in)	1.5 in
Bore Diameter (in)	1 in
Base to Center Height (in)	3.38 in
Foot Height (in)	0.38 in
Length Through Bore (in)	1.375 in
Bolt Spacing (in)	1.6250 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Bracket, Three Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Bearing Centerline to Bolt Hole Center (in)	1.8125 in
Bearing Insert Finish	Black Oxide
Grease Fitting Thread Size	1/4-28
Vibration Frequency Fundamental Train	0.0068 cps
Maximum Speed (RPM)	6350 rpm
Shaft Locking Type	Set Screw
Misalignment Capability	±2.0° Misalignment - Static Only
Inner Ring Outside Diameter (in)	1.375 in
Dynamic Load Rating (lb)	2,801 lb
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Outer Ring Defect	0.0682 cps
Bearing Type	Standard Duty
Cage Type	Land Riding Retainer
Insert	2-1C
Housing Material	Cast Iron
Fixed vs. Expansion	Fixed
End Cap Available	No
Housing Coating	Powder Coated
Size Code	2-015
Max Operating Temperature (F)	220 °F
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Inner Ring Defect	0.0985 cps
Bolt Spacing Height Direction (in)	1.125 in
Vibration Frequency Roller Spin	0.0442 cps
Radial Clearance	Standard
Static Load Rating (lb)	1,651 lb
Housing Width (in)	2.75 in

General Specifications

UPC	662461026007
Weight	1.62 LB
Packaged Length	1.69 IN
Packaged Width	3.19 IN
Packaged Height	5.25 IN
HTC	8483.20.4040
Country of Origin	United States of America
