• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal with black oxide bearing races
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	3/8 in
Overall Width (in)	2.38 in
Overall Height (in)	1.34 in
Overall Length (in)	4.19 in
Bore Diameter (in)	0.75 in
Base to Center Height (in)	3 in
Foot Height (in)	0.31 in
Length Through Bore (in)	1.219 in
Bolt Spacing (in)	1.5000 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Bracket, Three Bolt
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Cage Type	Land Riding Retainer
Shaft Locking Type	Set Screw
Misalignment Capability	±2.0° Misalignment - Static Only
Maximum Speed (RPM)	6450 rpm
Insert	2-012C
Vibration Frequency Roller Spin	0.0381 cps
Dynamic Load Rating (lb)	2,611 lb
Fixed vs. Expansion	Fixed
Static Load Rating (lb)	1,444 lb
Housing Coating	Powder Coated
Radial Clearance	Standard
Lubricant	Lithium Complex NLGI 2 Grease
Size Code	2-012
Bearing Insert Finish	Black Oxide
Grease Fitting Thread Size	1/4-28
End Cap Available	No
Bolt Spacing Height Direction (in)	0.875 in
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Outer Ring Defect	0.0593 cps
Max Operating Temperature (F)	220 °F
Bearing Centerline to Bolt Hole Center (in)	1.6875 in
Bearing Type	Standard Duty
Vibration Frequency Fundamental Train	0.0066 cps
Inner Ring Outside Diameter (in)	1.192 in
Vibration Frequency Inner Ring Defect	0.0907 cps
Housing Material	Cast Iron
Housing Width (in)	2.38 in

General Specifications

UPC	662461025970
Weight	1.15 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	United States of America
