• Powder coated epoxy cast iron housed, extended inner ring bearings in expansion ring allowing for axial expansion
• Skwezloc® concentric locking for near perfect concentricity
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	6.88 in
Bolt Size (in)	5/8 in
Overall Height (in)	2.75 in
Overall Length (in)	6.88 in
Bore Diameter (in)	2.25 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.83 in
Bolt Spacing (in)	5.6250 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Options	High Temperature
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	High Temp Labyrinth
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Locking Collar Outside Diameter (in)	4.22 in
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Radial Clearance	Standard
Fixed vs. Expansion	Expansion
Housing Material	Cast Iron
Bearing Insert Material	52100 Bearing Steel
Grease Fitting Thread Size	1/8 NPT
Inner Ring Outside Diameter (in)	2.981 in
Lubricant	Lithium Complex Grease With Synthetic Oil
Cage Type	Land Riding Retainer
Maximum Speed (RPM)	4100 rpm
Size Code	2-27
Static Load Rating (lb)	8,150 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Lube Fitting Type	HOUSING PLUGGED
Bearing Insert Finish	Black Oxide
Dynamic Load Rating (lb)	11,789 lb
Housing Backside Inner Diameter	5
Insert	AR 2-24T BMG
End Cap Available	No
Bearing Type	Standard Duty
Housing Coating	Powder Coated
Max Operating Temperature (F)	220 °F
Shaft Locking Type	Concentric

General Specifications

UPC	662461337165
Weight	11.80 LB
Packaged Length	7.19 IN
Packaged Width	7.00 IN
Packaged Height	3.31 IN
HTC	8483.20.4040
Country of Origin	United States of America
