Dimensions

Length Through Bore (in)	2.33 in
Bore Diameter (in)	2 in
Foot Height (in)	0.81 in
Overall Length (in)	6.38 in
Overall Width (in)	6.38 in
Bolt Size (in)	5/8 in
Overall Height (in)	2.375 in
Bolt Spacing (in)	5.1250 in

Technical Specifications

Housing Construction	One Piece
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	High Temperature Felt Labryinth Seal
Rolling Element	Ball Bearing
Outer Ring Land Profile	Standard
Bore Shape	Straight
Housing Type	Flange, Four Bolt
Housing Color	Black
Options	High Temperature
Misalignment Type	Static Only
Pilot Configuration	No Pilot
Housing Style	Flange Block
Locking Collar Outside Diameter (in)	3.6 in
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Inner Ring Outside Diameter (in)	2.723 in
Bearing Insert Material	52100 Bearing Steel
End Cap Available	No
Cage Type	Land Riding Retainer
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Backside Inner Diameter	4.25
Shaft Locking Type	Concentric
Bearing Type	Standard Duty
Max Operating Temperature (F)	400 °F
Radial Clearance	Increased
Maximum Speed (RPM)	4500 rpm
Fixed vs. Expansion	Expansion
Housing Coating	Powder Coated
Bearing Insert Finish	Black Oxide
Insert	AR 2-2T HI
Lubricant	Hight Temperature Synthetic Grease
Lube Fitting Type	HOUSING PLUGGED
Dynamic Load Rating (lb)	9,752 lb
Grease Fitting Thread Size	1/8 NPT
Static Load Rating (lb)	6,601 lb
Size Code	2-23
Housing Material	Cast Iron

General Specifications

UPC	662461336472
Weight	10.50 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
