• Powder coated epoxy cast iron housed, extended inner ring bearings in expansion ring allowing for axial expansion
• Skwezloc® concentric locking for near perfect concentricity
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	5.13 in
Bolt Size (in)	1/2 in
Overall Height (in)	2.078125 in
Overall Length (in)	5.13 in
Bore Diameter (in)	1.5 in
Foot Height (in)	0.56 in
Length Through Bore (in)	2 in
Bolt Spacing (in)	4.0000 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Options	High Temperature
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	High Temp Labyrinth
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	2.75 in
Ability to Relubricate	Yes
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	7,340 lb
Size Code	2-19
Bearing Insert Material	52100 Bearing Steel
Grease Fitting Thread Size	1/4-28
End Cap Available	No
Radial Clearance	Standard
Inner Ring Outside Diameter (in)	2.07 in
Housing Coating	Powder Coated
Max Operating Temperature (F)	400 °F
Static Load Rating (lb)	4,467 lb
Insert	AR-2-18T BMG
Lubricant	Lithium Complex Grease With Synthetic Oil
Maximum Speed (RPM)	5850 rpm
Shaft Locking Type	Concentric
Bearing Insert Finish	Black Oxide
Housing Backside Inner Diameter	3.5
Bearing Type	Standard Duty
Housing Material	Cast Iron
Misalignment Capability	±2.0° Misalignment - Static Only
Fixed vs. Expansion	Expansion

General Specifications

UPC	662461336274
Weight	5.50 LB
Packaged Length	5.50 IN
Packaged Width	2.13 IN
Packaged Height	5.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
