• ER style bearing with high phosphorous electroless nickel plated 52100 steel and corrosion resistant snap ring for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	1.44 in
Bore Size (in)	1 in
Outer Race Width (in)	0.75 in
Collar OD (in)	1.98 in
Centerline to Front Face (in)	0.922 in
Outer Race OD (mm)	52 mm
Inner Ring OD (in)	1.375 in
Outer Race OD (in)	2.0472 in
Length Through Bore (in)	1.44 in
Outer Race Width (mm)	19.1 mm

Technical Specifications

Torx Cap Screw	10-24 UNC
Insert Material	52100 Bearing Steel
Rolling Element	Ball Bearing
Housing Type	Insert (ER Style)
Set Screw Thread	10-24 UNC
Bore Shape	Straight
Measure Units	Inch
Seal Type	Triple Lip Contact Seal
Misalignment	None
Internal Clearance	Standard
Expansion	No
Outer Ring Land Profile	Tapered Lands
End Cap	No
Bearing Insert Coating	Phosphorus Nickel Coated
Platform	PN Gold
Misalignment Type	Static Only
Options	Corrosion Resistant
Certifications	IP69K
Precision Rating	ABEC 1
Cage Material	PPS - Polyphenylene Sulfide
Inner Race Profile	Wide Inner Ring
Outer Race Profile	Cylindrical
Lubrication Type	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Maximum Speed (rpm)	2700 rpm
Vibration Frequency Fundamental Train	0.0068 cps
Maximum Operating Temperature (F)	220 °F
Inner Ring Fillet Radius (in)	0.04 in
Vibration Frequency Outer Ring Defect	0.0682 cps
Ability to Relubricate	Yes
Series	Unmounted Replacement Bearings
Setscrew Torque (in-lbs)	70 in/lbs
Size Code	2-015
Vibration Frequency Roller Spin	0.0442 cps
Locking Type	Concentric
Inner Race Heat Treat Method	Zone-Hardened
Vibration Frequency Inner Ring Defect	0.0985 cps
Duty/Status	Standard
Dynamic Load Rating (lb)	2,801 lb
Cage Type	Land Riding Retainer
Static Load Rating (lb)	1,651 lb

General Specifications

UPC	662461340028
Weight	0.70 LB
Packaged Length	2.38 IN
Packaged Width	1.44 IN
Packaged Height	2.38 IN
HTC	8482.10.5048
Country of Origin	Mexico
