• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy 2-bolt split cast iron housing

Dimensions

Overall Width (in)	4 in
Overall Height (in)	5.75 in
Overall Length (in)	10.375 in
Bolt Size (in)	0.625 in
Base Width (in)	3.406 in
Bore Size (in)	2.4375 in
Inner Race Length (in)	4 in
Bolt Center Max (in)	8.688 in
Foot Height (in)	1.625 in
Bolt Center Min (in)	6.938 in
Base to Center Height (in)	2.75 in
Centerline to Front Face (in)	2 in
Collar Outer Diameter (in)	3.938 in

Technical Specifications

Measure Units	Inch
Housing Material	Cast Iron
Housing Type	Pillow Block, Two Bolt
Expansion	Yes
Rolling Element	Tapered Roller
Seal Type	Single Lip Contact Seal
Insert Material	52100 Bearing Steel
Housing Base	Solid
Housing Construction	Split Two Piece
Bore Shape	Straight
Locking Type	Double Collar Mount
Speed (Max)	2000
Radial Dynamic Load Capacity (lb)	9,030 lb
Internal Clearance	Standard
Misalignment	±3.0° Misalignment - Static Only
Replaceable Insert	Yes
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Retainer Material	Steel
Housing Color	Gray
Bearing Insert Coating	Uncoated
End Cap	No
Platform	RPB Series
Series	ERPB
Grease Fitting Thread Size	1/8 NPT
Lubrication Type	Lithium; EP; NLGI#2
Insert Number	ERCI-207C
Maximum Operating Temperature (F)	220 °F
Ability to Relubricate	Yes
Duty/Series	Standard
Inner Race Heat Treat Method	Case Carburized Inner Ring
Housing Style	Pillow Block

General Specifications

UPC	662288482024
Weight	22.00 LB
Packaged Length	10.50 IN
Packaged Width	5.88 IN
Packaged Height	4.13 IN
HTC	8483.20.8080
Country of Origin	United States of America
