• Powder coated epoxy cast iron housed, extended inner ring bearings in expansion ring allowing for axial expansion
• Zone hardened inner ring with 120° spacing setscrew locking on both sides of ball path with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	3.50 in
Base Width (in)	3.50 in
Overall Height (in)	7.25 in
Overall Length (in)	13 in
Bolt Size (in)	7/8 in
Bore Diameter (in)	2.9375 in
Foot Height (in)	1.25 in
Base to Center Height (in)	3.5000 in
Length Through Bore (in)	3.498 in
Bolt Spacing Max (in)	10.13 in
Centerline to Outermost Bearing Face (in)	1.938 in
Bolt Spacing Min (in)	7.88 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Housing Construction	One Piece
Bore Shape	Straight
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	Brass
Seal Type	High Temp Labyrinth
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Setscrew Torque (in-lbs)	500-650 in/lbs
Inner Ring Outside Diameter (in)	3.641 in
Housing Material	Cast Iron
Cage Type	Land Riding Retainer
Housing Coating	Powder Coated
Max Operating Temperature (F)	220 °F
Static Load Rating (lb)	11,224 lb
Lubricant	Lithium Complex Grease With Synthetic Oil
Radial Clearance	Standard
End Cap Available	No
Dynamic Load Rating (lb)	14,839 lb
Vibration Frequency Fundamental Train	0.0069 cps
Fixed vs. Expansion	Expansion
Misalignment Capability	±2.0° Misalignment - Static Only
Expansion Capability (in)	.25 in
Vibration Frequency Outer Ring Defect	0.0759 cps
Vibration Frequency Inner Ring Defect	0.1074 cps
Grease Fitting Thread Size	1/8 NPT
Maximum Speed (RPM)	3400 rpm
Vibration Frequency Roller Spin	0.0470 cps
Shaft Locking Type	Double Set Screw
Base Length (in)	13.00 in
Insert	2-215D MA
Bearing Insert Material	52100 Bearing Steel
Size Code	2-215
Bearing Insert Finish	Black Oxide
Bearing Type	Medium Duty

General Specifications

UPC	662461300343
Weight	30.90 LB
Packaged Length	14.25 IN
Packaged Width	8.06 IN
Packaged Height	4.00 IN
HTC	8483.20.8040
Country of Origin	United States of America
