• Powder coated epoxy cast iron housed, extended inner ring bearings in expansion ring allowing for axial expansion
• Zone hardened inner ring with 120° spacing setscrew locking on both sides of ball path with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Base Width (in)	3.50 in
Overall Length (in)	13 in
Overall Width (in)	3.50 in
Overall Height (in)	7.00 in
Bolt Size (in)	7/8 in
Bore Diameter (in)	2.6875 in
Foot Height (in)	1.13 in
Base to Center Height (in)	3.5000 in
Length Through Bore (in)	3.500 in
Bolt Spacing Min (in)	7.88 in
Centerline to Outermost Bearing Face (in)	1.750 in
Bolt Spacing Max (in)	10.13 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	Brass
Seal Type	Felt Labyrinth Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Setscrew Torque (in-lbs)	500-650 in/lbs
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Vibration Frequency Outer Ring Defect	0.0761 cps
Housing Material	Cast Iron
Insert	AR-2-211D
Static Load Rating (lb)	11,224 lb
Vibration Frequency Fundamental Train	0.0069 cps
Fixed vs. Expansion	Expansion
Max Operating Temperature (F)	220 °F
Bearing Insert Material	52100 Bearing Steel
Misalignment Capability	±2.0° Misalignment - Static Only
Shaft Locking Type	Double Set Screw
Radial Clearance	Standard
Housing Coating	Powder Coated
Bearing Type	Medium Duty
Vibration Frequency Roller Spin	0.0476 cps
Maximum Speed (RPM)	3600 rpm
Grease Fitting Thread Size	1/8 NPT
Lubricant	Lithium Complex NLGI 2 Grease
Dynamic Load Rating (lb)	14,839 lb
Cage Type	Land Riding Retainer
End Cap Available	No
Size Code	2-215
Inner Ring Outside Diameter (in)	3.641 in
Base Length (in)	13.00 in
Bearing Insert Finish	Black Oxide
Vibration Frequency Inner Ring Defect	0.1072 cps
Expansion Capability (in)	.19 in

General Specifications

UPC	662461061312
Weight	29.70 LB
Packaged Length	14.25 IN
Packaged Width	8.06 IN
Packaged Height	4.00 IN
HTC	8483.20.8040
Country of Origin	United States of America
