• Powder coated epoxy cast iron housed, extended inner ring bearings in expansion ring allowing for axial expansion
• Skwezloc® concentric locking for near perfect concentricity
• Extra low drag seal cut down felt labyrinth seal and flinger
• Nylon retainer to reduce overall drag
• Oil lubricated and supplied with an adapter and plug for easy field relubrication
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation
• Looser than standard housing fit for ease of alignment on lightweight frames

Dimensions

Overall Length (in)	5.5 in
Base Width (in)	2.00 in
Overall Width (in)	2.00 in
Overall Height (in)	3.44 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1 in
Base to Center Height (in)	1.7500 in
Foot Height (in)	0.63 in
Length Through Bore (in)	1.563 in
Bolt Spacing Max (in)	5.19 in
Centerline to Outermost Bearing Face (in)	0.938 in
Bolt Spacing Min (in)	4.19 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Options	Extra Low Drag
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Two Bolt
Seal Type	Labryinth Seal
Housing Style	Pillow Block
Locking Collar Outside Diameter (in)	2.06 in
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Lubricant	Oil Coated Only - No Factory Grease Fill
Dynamic Load Rating (lb)	2,801 lb
Cage Type	Land Riding Retainer
Fixed vs. Expansion	Expansion
Insert	AR-2-1T XLO
Misalignment Capability	±2.0° Misalignment - Static Only
Maximum Speed (RPM)	2150 rpm
Base Length (in)	6.25 in
Vibration Frequency Outer Ring Defect	0.0682 cps
Housing Coating	Powder Coated
End Cap Available	No
Size Code	2-015
Vibration Frequency Fundamental Train	0.0068 cps
Bearing Type	Medium Duty
Housing Material	Cast Iron
Bearing Insert Finish	Black Oxide
Grease Fitting Thread Size	1/4-28
Radial Clearance	Standard
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Roller Spin	0.0442 cps
Static Load Rating (lb)	1,651 lb
Shaft Locking Type	Concentric
Max Operating Temperature (F)	220 °F
Vibration Frequency Inner Ring Defect	0.0985 cps
Inner Ring Outside Diameter (in)	1.594 in

General Specifications

UPC	662461343982
Weight	3.90 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
