• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy 2-bolt split cast iron housing

Dimensions

Overall Width (in)	4.5 in
Bolt Size (in)	0.75 in
Base Width (in)	3.125 in
Overall Height (in)	7 in
Bolt Center-to-Center Length (in)	10.435 in
Overall Length (in)	13.5 in
Bore Size (in)	2.9375 in
Base to Center Height (in)	3.75 in
Bolt Center Max (in)	11.563 in
Centerline to Front Face (in)	2.25 in
Bolt Center Min (in)	9.313 in
Inner Race Length (in)	4.5 in
Foot Height (in)	2 in
Collar Outer Diameter (in)	4.719 in

Technical Specifications

Housing Base	Solid
Rolling Element	Tapered Roller
Measure Units	Inch
Seal Type	Single Lip Contact Seal
Insert Material	52100 Bearing Steel
Housing Material	Cast Iron
Expansion	No
Housing Type	Pillow Block, Two Bolt
Housing Construction	Split Two Piece
Internal Clearance	Standard
Misalignment	±3.0° Misalignment - Static Only
Locking Type	Double Collar Mount
Speed (Max)	1750
Bore Shape	Straight
Radial Dynamic Load Capacity (lb)	9,630 lb
Misalignment Type	Static Only
Housing Color	Gray
Outer Ring Land Profile	Standard
Bearing Insert Coating	Uncoated
End Cap	No
Replaceable Insert	Yes
Retainer Material	Steel
Platform	RPB Series
Series	DRPB
Grease Fitting Thread Size	1/8 NPT
Ability to Relubricate	Yes
Duty/Series	Standard
Housing Style	Pillow Block
Maximum Operating Temperature (F)	220 °F
Lubrication Type	Lithium; EP; NLGI#2
Insert Number	RCI-215C
Inner Race Heat Treat Method	Case Carburized Inner Ring

General Specifications

UPC	662288485872
Weight	35.20 LB
Packaged Length	13.88 IN
Packaged Width	8.00 IN
Packaged Height	5.13 IN
HTC	8483.20.8080
Country of Origin	United States of America
