• Three-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Left-Hand Threads
• Delrin Race

Dimensions

Ball Flat Diameter (in)	0.447 in
Thread Size	#5/16-24
Ball Width (in)	0.437 in
Ball Diameter (in)	0.625 in
Head Diameter (in)	0.875 in
Thread Length (in)	1.219 in
Housing Width (in)	0.344 in
Length to Center of Ball (in)	1.88 in

Technical Specifications

Bearing Type	Rod End
Housing Style	Male Rod End
Series	Commercial
Product Type	CTMD
Misalignment Angle - a Deg. +/-	7
Lubrication Type	Self Lubricating
Product Selection Available SW	Y
Liner	DELRIN* Liner
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Thread Type	UNF
Zerk Fitting SW	N
Construction	Three-Piece Rod End
Outer Material	Carbon Steel - Corrosion Resistant Plating
Axial Load	157
Configuration	Male
Race Material	DELRIN
Thread	LH
Max Static Radial Load	1,570
Type	Male Rod End
Lubrication	No Zerk Fitting
Class	Commercial
Bore Size (in)	0.3125 in
Lubrication Method	Self Lubricating
Maximum Ambient Temperature (F)	150 °F
Ability to Relubricate	Self

General Specifications

UPC	662288725886
Weight	0.08 LB
Packaged Length	2.31 IN
Packaged Width	0.88 IN
Packaged Height	0.44 IN
HTC	8483.30.8055
Country of Origin	Mexico
