• Three-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• Delrin Race

Dimensions

Thread Length (in)	1.219 in
Housing Width (in)	0.406 in
Thread Size	#3/8-24
Ball Flat Diameter (in)	0.517 in
Ball Diameter (in)	0.718 in
Ball Width (in)	0.5 in
Head Diameter (in)	1 in
Length to Center of Ball (in)	1.94 in

Technical Specifications

Product Selection Available SW	Y
Outer Material	Carbon Steel - Corrosion Resistant Plating
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Series	Commercial
Construction	Three-Piece Rod End
Configuration	Male
Housing Style	Male Rod End
Liner	DELRIN* Liner
Bearing Type	Rod End
Product Type	CTMD
Misalignment Angle - a Deg. +/-	6
Zerk Fitting SW	N
Lubrication Type	Self Lubricating
Race Material	DELRIN
Axial Load	215
Thread Type	UNF
Thread	RH
Type	Male Rod End
Lubrication	No Zerk Fitting
Max Static Radial Load	2,150
Class	Commercial
Bore Size (in)	0.3750 in
Lubrication Method	Self Lubricating
Maximum Ambient Temperature (F)	150 °F
Ability to Relubricate	Self

General Specifications

UPC	662288725817
Weight	0.11 LB
Packaged Length	2.44 IN
Packaged Width	1.00 IN
Packaged Height	0.50 IN
HTC	8483.30.8055
Country of Origin	Mexico
