• Three-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• Delrin Race

Dimensions

Thread Size	#10-32
Thread Length (in)	0.719 in
Ball Width (in)	0.312 in
Housing Width (in)	0.25 in
Ball Diameter (in)	0.437 in
Head Diameter (in)	0.625 in
Ball Flat Diameter (in)	0.306 in
Length to Center of Ball (in)	1.25 in

Technical Specifications

Construction	Three-Piece Rod End
Configuration	Male
Liner	DELRIN* Liner
Zerk Fitting SW	N
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Product Selection Available SW	Y
Bearing Type	Rod End
Misalignment Angle - a Deg. +/-	6.5
Axial Load	80
Lubrication Type	Self Lubricating
Race Material	DELRIN
Outer Material	Carbon Steel - Corrosion Resistant Plating
Series	Commercial
Housing Style	Male Rod End
Product Type	CTMD
Thread Type	UNF
Max Static Radial Load	800
Lubrication	No Zerk Fitting
Thread	RH
Type	Male Rod End
Class	Commercial
Bore Size (in)	0.1875 in
Lubrication Method	Self Lubricating
Maximum Ambient Temperature (F)	150 °F
Ability to Relubricate	Self

General Specifications

UPC	662288725787
Weight	0.03 LB
Packaged Length	1.56 IN
Packaged Width	0.63 IN
Packaged Height	0.31 IN
HTC	8483.30.8055
Country of Origin	Mexico
