• Three-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• Delrin Race

Dimensions

Ball Flat Diameter (in)	0.978 in
Ball Diameter (in)	1.312 in
Head Diameter (in)	1.75 in
Housing Width (in)	0.687 in
Ball Width (in)	0.875 in
Thread Length (in)	1.719 in
Thread Size	#3/4-16
Length to Center of Ball (in)	2.88 in

Technical Specifications

Race Material	DELRIN
Misalignment Angle - a Deg. +/-	7
Bearing Type	Rod End
Liner	DELRIN* Liner
Construction	Three-Piece Rod End
Series	Commercial
Zerk Fitting SW	N
Thread Type	UNF
Housing Style	Female Rod End
Product Selection Available SW	Y
Configuration	Male
Outer Material	Carbon Steel - Corrosion Resistant Plating
Lubrication Type	Self Lubricating
Product Type	CTMD
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Axial Load	660
Max Static Radial Load	6,600
Type	Male Rod End
Lubrication	No Zerk Fitting
Thread	RH
Class	Commercial
Bore Size (in)	0.7500 in
Lubrication Method	Self Lubricating
Maximum Ambient Temperature (F)	150 °F
Ability to Relubricate	Self

General Specifications

UPC	662288725855
Weight	0.58 LB
Packaged Length	3.75 IN
Packaged Width	1.75 IN
Packaged Height	0.88 IN
HTC	8483.30.8055
Country of Origin	Mexico
