• Three-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• Delrin Race

Dimensions

Ball Diameter (in)	1.312 in
Base Diameter (in)	1.125 in
Ball Width (in)	0.875 in
Head Diameter (in)	1.75 in
Housing Width (in)	0.687 in
Ball Flat Diameter (in)	0.978 in
Thread Length (in)	1.719 in
Thread Size	#3/4-16
Length to Center of Ball (in)	2.88 in

Technical Specifications

Outer Material	Carbon Steel - Corrosion Resistant Plating
Series	Commercial
Misalignment Angle - a Deg. +/-	7
Race Material	DELRIN
Axial Load	660
Lubrication Type	Self Lubricating
Configuration	Female
Liner	DELRIN* Liner
Product Selection Available SW	Y
Across Wrench Flats	1
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Construction	Three-Piece Rod End
Bearing Type	Rod End
Housing Style	Female Rod End
Zerk Fitting SW	N
Product Type	CTFD
Thread Type	UNF
Lubrication	No Zerk Fitting
Max Static Radial Load	6,600
Type	Female Rod End
Thread	RH
Class	Commercial
Bore Size (in)	0.7500 in
Lubrication Method	Self Lubricating
Ability to Relubricate	Self
Maximum Ambient Temperature (F)	150 °F

General Specifications

UPC	662288726012
Weight	0.60 LB
Packaged Length	3.75 IN
Packaged Width	1.75 IN
Packaged Height	1.00 IN
HTC	8483.30.8055
Country of Origin	Mexico
